LumenDimM6 Miniature CRMX or W-DMX wireless DMX dimmer, 6 channels

759,00  *

Available on backorder

Wireless low-voltage DMX-controlled 6-channel dimmer for theatre and motion picture. Control LEDs & lamps in small props, costumes, and more. Genuine LumenRadio CRMX technology, compatible with all CRMX devices widely used in the motion picture industry.

Available on backorder

SKU: rld6m Categories: , Tags: , ,

Description

The LumenDimM6 is a battery-powered 6-channel wireless DMX dimmer that combines the best RC4 Harmonized Design™ features with a genuine LumenRadio TiMo radio transceiver. The LumenDimM6 includes a built-in radio receiver and six pulse-width-modulation (PWM) dimmers.

included in delivery: external antenna

RC4 digital persistance iconIt includes 19-bit dimming, which is eight times finer than 16-bit with a whopping 524,000 steps of resolution. The digital persistance for ISL dimming curve simulates the behavior of a tungsten lamp for LED with no visible stepping.

The LumenDimM6 also features dimmer curve tweaking to find the most visually linear and pleasing response with any LED technology being used.

OneTouch

RC4 wireless key featureThe RC4 LumenDimM6 provides two versatile dimmer outputs.  Like all RC4Magic devices, it includes a built-in radio receiver and uses RC4 OneTouch™ for easy assignment of any DMX channel and dimmer curve to any dimmer with a single press of a single button.

RDM

RDM (remote device management) for RC4 dimmersDevice configuration can also be done with Remote Device Management (RDM) wireless or wired.

HSL Color Controller

Two channels are ideal for hybrid-white LED color-mixing, to transition between different color temperatures of white.  The RC4 Hue/Saturation/Level (HSL) Color Controller delivers best-in-class color consistency over the entire dimming range, ensuring precise mix ratios even at very low dimmer levels using 16-bit (65,536 step) dimming.  Unlike single-channel DMX control of color from a console, which is limited to 256 steps and becomes heavily quantized at low levels, the RC4 HSL Color Controller maintains high ratiometric precision throughout the dimming range.

ColorMatch

RC4 wireless key featureIn addition, RC4 ColorMatch™ on the LumenDimM6 makes it easy to calibrate intensity between two light sources.

PWM

RC4 wireless key featureMany pulse-width-modulation (PWM) dimmers look good to the human eye, but produce banding, blinking, and other anomalies when used with video cameras. For this reason, all RC4 Series 3 dimmers provide multiple PWM frequencies.  Low frequencies are most efficient, ideal for high-wattage incandescent lighting. Mid frequencies improve the appearance of LEDs by eliminating visible strobing in human peripheral vision.  High frequencies eliminate video artifacts.  And finally, supersonic PWM frequencies, though least efficient for power handling, provide PWM dimming without audio interference when used near microphones and electrified musical instruments.

MOTOR CONTROL

RC4 wireless key featureThis dimmer can control the speed and direction of DC motors, stepper motors and the position of hobby servo motors.

For direction control, a second dimmer output can be used to flip a relay that reverses the DC motor connectors – polarity of power directly controls spin direction.

DMX IN/OUT

The LumenDimM6, and all RC4 Series 3 dimmers, provide a wired DMX data port.  In most cases this port is used to output data to nearby fixtures including fog machines, moving lights, and projector dousers.  The DMX port can also be configured as a DMX input, allowing the LumenDimM6 to be used as a wired dimmer.  In this mode, a comprehensive RDM implementation includes E1.37 dimmer configuration parameters, numerous status sensors (voltage, temperature, current), and each individual dimmer appears as an RDM sub-device.

The RC4 DMX miniplug port can used with a range of DMX adaptors, including 3-pin and 5-pin male and female XLR connectors.  The most common adaptor is the RC4DMX5FA with 5-pin female XLR connector.

Connection

Screw terminals are provided for connection of the power supply (DC IN) and load devices (DimA to DimF). The supply powers both the internal electronics and the connected loads. Dimmers switch on the negative side of the circuit, ideal for common-anode (common positive) LED tape. Dimmer output voltage is precisely the DC power input voltage with no appreciable losses within the 16A total power handling limit of the device

close

Get News!

About special offers, new functions, hints, wireless DMX skills.

We promise not to send spam! Learn more in our data security statement.

Additional information

Weight 0.15 kg

Specifications

  • Dimensions:  3.14″x 1.5″ x .78″ (80mm x 40mm x 20mm)
  • Weight: 2.20oz (65g)
  • Power Input: 6VDC – 35VDC, 0.5W, screw terminals
  • Dimmer Outputs: 6 low-voltage DC dimmers, screw terminals, 19-bit resolution PWM (524,00 steps)
  • Output Power, per Dimmer: 10A non-continuous, 5A continuous
  • Maximum Total Power Handling: 16A (limited by safety rating of input screw terminals)
  • Multiple PWM Frequencies: 77Hz (high power), 615Hz (flicker free), 5kHz (artifact free for video), 20kHz (noise free for audio), 40kHz (super-slow-motion video)
  • Multiple Dimmer Curves: Non-Dim, Non-Dim Inverted, Linear, Linear Inverted, Inverse-Square-Law (ISL), ISL inverted, servo motor pulse clockwise (CW), servo motor pulse counter-clockwise (CCW), AC wave (ring telephone bells)
  • DMX Input/Output: RC4 3.5mm mini, USITT DMX512/1990 data, non-standard port, connector adaptors available. RDM E1.20 and E1.37 (dimmer configuration) support
  • Wireless DMX Protocol: LumenRadio CRMX
  • RF Antenna: RP-SMA external, omnidirectional. Alternate antennas can be used for increased sensitivity and directionality
